T50 DUAL-SCREEN GCS

Product Details

T50 Dual Screen Drone Ground Station,This exciting ground station features dual 17" HD displays with 1,000 brightness and a touch capacitive screen for a great control experience. Built-in high performance with i7 12-core CPU, 32GB RAM, and 1TB storage allows you to process data with less effort.

With a focus on the user experience, we've given you 27 physical channels and two telescopic master telepods, and the freedom to edit the channel settings to ensure precision in every manoeuvre. This is not only a technological leap forward, but also a respect for the operator.

With built-in digital transmission links up to 150KM, the T50 ground station offers a wider range of coverage for your missions. We easily support the integration of friendly links, breaking traditional constraints and offering more possibilities for your missions.

In this era of technology, T50 will create the future together with you, and open up an unprecedented technological journey for you. Whether you are a professional pilot or a beginner, the T50 ground station will be your drone in the palm of your hand, helping you to master the sky and create infinite possibilities! Stay tuned and soar into the future with T50!

Features

Robust Computing Power

Equipped with an INTEL i7 1260PCPU, ensuring exceptionalprocessing power and multitaskingcapabilities

Precise Control

Features retractable three-axis joystick with hall-effect, providing a precise control experience.

Highly Integrated System

R&D totally in-house, our components stand out from the simple connections of off-the- shelf parts used by other manufacturers, ensuring superior compatibility and reliability

Precision Switch

Multi-segment switches with freely definable attributes

Innovative Damping Design

Breaks away from traditional

support rod solutions, it delivers

a more stable support structure.

Enhanced Security

Increased security with protective caps on buttons, improving device safety and

resistance to damage.

Multifunctional Keyboard

Keyboard can be with a mouse for

additional control options, enhancing

user convenience.

Multi-Interface Design

Device supports multiple interfaces, allowing easy adaptation to our video links and third-party devices, expanding device applicability.

T50 Product Parameters

Dimension
Overall weight	20 Kg （Battery included 2.8kg）
Dimension	850mm(L)425mm(W)160mm(H)
Screen size	17 inch 12801024 1000nit2 (bottom screen)

Computer Peripherals
CPU	Intel i7 1260P (standard)
Touch pad	10-finger capacitive touch screen
Operating system	Windows11 / Linux
RAM	32G (standard)
SSD storage	1T (standard) \ 2T
Network	WIFI/Bluetooth(standard) 4G(optional)
Interfaces	HDMI in \ USB3.0 \ LAN \ Type-c

Remote Control
Physical channel	27
Human interface	USB HID
Remote control function	Dual SBUS independent output, able to control the vehicle and the payload simultaneously
SBUS port	SBUS IN1; SBUS OUT2
Remote control latency	40ms
IP rating	IP53(in open status) IP65(in closed status)

Battery Peripherals
Battery capacity	DC 25.2V/30000mAh (external power source also supported)
Working time	5 hs@full battery capacity
Charging port	DC 25.2v
Charging port	-20 ~ 60 ℃

Communication link
V21/V31	5-150km grade video&telemetry&RC link
The 3rd party communication link	Supported
